MSI MAG Series CORELIQUID 280R, aRGB CPU Liquid Cooler (AIO): Rotatable Blockhead Design, 280mm Radiator, Dual 140mm RGB PWM Fans

MSI MAG Series CORELIQUID 280R, aRGB CPU Liquid Cooler (AIO): Rotatable Blockhead Design, 280mm Radiator, Dual 140mm RGB
PWM Fans



List Price:$119.99 Details
With Deal:$94.99 & FREE Returns
You Save:$25.00 (21%)
Item Dimensions LxWxH12.28 x 1.06 x 5.51 inches
BrandMSI
Cooling MethodWater
Noise Level16.7 dB

About this item

  • Long Lasting Reliability: A durable three phase motor at the core of the pump generates minimal vibrations for long-lasting operation.
  • Total RGB Fan Control: The included RGB fans support custom speed with a PWM fan and customizable lighting through software.
  • Rotatable Cap: Mount the cold plate in any orientation, and turn the cap up to 270 degrees to keep it upright.
  • Radiator Pump Design: The pump has been integrated into the radiator for noise reduction as well as increased life expectancy due to being away from the heat source.
  • Compatible Sockets & CPU: Intel LGA1150/1151/1155/1156/1200, LGA1366, LGA2011, LGA2011-3, LGA2066 / AMD AM4, FM2+, FM2, FM1, AM3+, AM3, AM2+, AM2, TR5



RADIATOR PUMP DESIGN

The pump has been integrated into the radiator for sound dampening and noise reduction.



PUMP MOTOR RESONANCE ELIMINATION

A durable three-phase motor at the core of the pump generates minimal vibrations.


HIGH THERMAL DISSIPATION

A split pathway through the radiator rapidly dissipates heat


EVAPORATION PROOF TUBING

Constructed with three layers of netted plastic tubing and a reinforced mesh exterior.

EXTENSIVE COMPATIBILITY

Intel: LGA 1150, 1151, 1155, 1156, LGA1200, LGA1366, LGA2011, LGA2011-3, LGA2066

AMD: AM4, FM2+, FM2, FM1, AM3+, AM3, AM2+, AM2


MAG CORELIQUID 240R Technical Specifications

Number of Fans / Fan Dimension2 / 140 x 140 x 25mm
Fan Speed500 - 1800 RPM
Fan Power / Current / Voltage2.28 W / 0.19 A / 12V DC
Fan BearingTwo Ball Bearing
Fan Air Pressure2.29 mmH2O
Fan Noise Level14.8 - 33.28 dBA
Fan Air Flow84.36 CFM
Fan Cables Lengths350 mm / 13.78 inches (4-pin PWM), 550 mm / 21.65 inches (5V ARGB)
Radiator Dimensions312 x 140 x 27mm / 12.28 x 5.51 x 1.06 inches
Radiator Tubing Length400 mm / 15.75 inches
Pump Block Dimensions80.57x 66.82 x 48.58 mm / 3.17 x 2.63 x 1.91 inches
Block ARGB 5V Cable Length400 mm / 15.75 inches
Pump Power / Current / Voltage4.08 W / 0.34 A / 12V DC
Accessories1 to 2 Fan PWM cable; PSU Molex 4-Pin to 4-Pin (2 Pin Wired) Fan cable
Intel Socket CompatibilityLGA 1150 / 1151 / 1155 / 1156 / 1200, LGA 1366 / 2011 / 2011-3 / 2066
AMD Socket CompatibilityAM4 / FM2+ / FM2 / FM1 / AM3+ / AM3 / AM2+ / AM2

Installation Guide


Step-by-Step Installation Videos for MAG CORELIQUID Series


Step-by-step videos provided by MSI demonstrate the MAG CORELIQUID Series secure installation procedure for a number of Intel and AMD motherboards.

Intel Socket LGA 1150/1151/1155/1156/1200/1366

Step-by-Step Installation Videos for MAG CORELIQUID Series


Demonstrated on Intel LGA1200 motherboard. Similar steps for LGA 1150, 1151, 1155, 1156, and 1366 socket motherboards.



AMD Socket AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2

Step-by-Step Installation Videos for MAG CORELIQUID Series


Demonstrated on AMD AM4 motherboard. Similar steps for FM2+, FM2, FM1, AM3+, AM3, AM2+, and AM2 socket motherboards.




Intel Socket LGA 2011/2011-3/2066

Step-by-Step Installation Videos for MAG CORELIQUID Series


Demonstrated on Intel LGA2066 motherboard. Similar steps for LGA2011, and LGA2011-3 socket motherboards.





AMD Socket sTR4/sTRX4/SP3

Step-by-Step Installation Videos for MAG CORELIQUID Series


Demonstrated on AMD sTRX4 motherboard. Similar steps for sTR4, and SP3 socket motherboards.
